120 μm HDPE Release Film No Solvent No Silicone Transfer Without Residuals

120 μm HDPE Release Film No Solvent No Silicone Transfer Without Residuals

  • Highlight

    HDPE Release high density film

    ,

    hdpe plastic film No Solvent

    ,

    high density film 120micron

  • Material
    High Density Polyethylene
  • Color
    White, Customized
  • Halogen Free
    Yes
  • Thickness
    120μm ± 8%
  • Width
    1200 ± 5mm
  • Core
    3" Or 6"
  • Coating
    Single Side UV Cured Silicone Coating
  • Release Force
    10-15gf, Customized
  • Subsequent Adhesion Rate
    ≥75%
  • Length
    1800 ± 200m, Customized
  • Splice
    ≤1
  • Sample
    A4 Sheet For Free
  • Place of Origin
    China
  • Brand Name
    HSF
  • Model Number
    120WSS15-PE
  • Minimum Order Quantity
    10000㎡
  • Packaging Details
    PE wrapping film + Bubble film + Wooden pallet (W.1100mm x L. 1100mm x H. 100mm), customized
  • Delivery Time
    within 10 days
  • Payment Terms
    T/T, L/C
  • Supply Ability
    80000kg per week

120 μm HDPE Release Film No Solvent No Silicone Transfer Without Residuals

HDPE Release Film, S,120micron, White, UV Cured, Application of Tape, Sealing strip, No solvent, No Silicone transfer.



1 Appearance No air bubbles / stains / breakage / impurities Measured data (Ref.)
2 Size Width (mm) 1200 ± 5 1200
Thickness (mm) 0.120 ± 8% 0.123
3 Color difference Colorimeter E 3 ok
4 Tensile Strength (Mpa) TD ≥ 15 19
MD ≥ 15 28
5 Elongation @ break (%) TD ≥ 230 863
MD ≥ 230 939
6 Surface Tension (Corona treatment) Dyne Value ≥42 dyne 49
7 Release Force (gf/25mm 20min.Finat 10) 10-15 11
8 Subsequent Adhesion (%) ≥ 75 90
9 Winding direction Customized -
10 Splice No. ≤1 -



HDPE (low-pressure high-density polyethylene):

Non-toxic, tasteless, odorless white powder or columnar or semi-circular particles,

with wear resistance, capacitance resistance, water impermeability, flammability, poor flexibility.

The melting point is about 130°C, and the relative density is 0.941-0.965g/cm³. it has good heat and cold resistance,

good chemical stability, high rigidity and toughness, good mechanical strength, dielectric properties,

and environmental stress cracking resistance are excellent as well.

The product is widely used as an ideal material for various tapes, sealing strips, etc.
