50 μm White LDPE Release Film Low Density Polyethylene Film, No Silicone Transfer No Residuals Mainly for Tapes

50 μm White LDPE Release Film Low Density Polyethylene Film, No Silicone Transfer No Residuals Mainly for Tapes

  • Highlight

    low density polyethylene film White

    ,

    LDPE Release Film 50um

    ,

    low density polyethylene film 50micron

  • Material
    Low Density Polyethylene
  • Color
    White, Customized
  • Halogen Free
    Yes
  • Thickness
    50 ± 5μm, Customized
  • Width
    1300 -0 ~ +6mm, Customized
  • Core
    3" Or 6"
  • Coating
    Single Side UV Cured Silicone Coating
  • Release Force
    3-5gf, Customized
  • Subsequent Adhesion Rate
    ≥75%
  • Length
    4500m ± 200m, Customized
  • Splice
    ≤1
  • Sample
    A4 Sheet For Free
  • Place of Origin
    China
  • Brand Name
    HSF
  • Model Number
    50WSS5-LPE
  • Minimum Order Quantity
    10000㎡
  • Packaging Details
    PE wrapping film + Bubble Film + Wooden pallet (Standard 1100mm x 1100mm x 100mm)
  • Delivery Time
    within 10 days
  • Payment Terms
    T/T, L/C
  • Supply Ability
    80000kg per week

50 μm White LDPE Release Film Low Density Polyethylene Film, No Silicone Transfer No Residuals Mainly for Tapes

LDPE Release Film, S, 50micron, White, UV Cured, Application of Tape, Sealing strip, No solvent or silicone transfer.



1 Appearance No air bubbles / stains / breakage / impurities Measured data (Ref.)
2 Size Width (mm) 1300 -0+6 1302
Thickness (mm) 0.050 ± 0.005 0.051
3 Tensile Strength (Mpa) TD ≥ 15 20
MD ≥ 15 20
4 Color difference Colorimeter E 3 ok
5 Elongation @ break (%) TD ≥ 230 1028
MD ≥ 230 584
6 Surface Tension (Corona treatment) Dyne Value ≥42 dyne 48
7 Release Force (gf/25mm) 3-5 4
8 Subsequent Adhesion (%) ≥ 75 85
9 Winding direction Customized -
10 Splice No. ≤1 -



LDPE (high pressure low density polyethylene):

Non-toxic, tasteless, odorless, translucent spherical or cylindrical particles, excellent low temperature resistance,

chemical resistance, good extensibility, electrical insulation, but poor wetness, Flammable.

Density: 0.910—0.9408g/cm³, suitable for extrusion, blister, injection molding, vacuum, molding, and conversion

molding and other processing methods. The crystallinity is 55-65%, and the crystal melting point is 108-126 °C.
